Sensor: 1280 x 800 pixels Resolution: 4 mil Print Contrast Ratio: 25% Scanning angle from 55° (H) x 45° (V) Depth of Field: Code 39 30mm~135mm (5mil) EAN13 35mm~220mm (13mil) QR CODE 45mm~460mm (20mil) Data Matrix 25mm~180mm (10mil) PDF417 30mm~160mm (6.67mil)
Supported Symbologies: 1D:Code128, EAN-13, EAN-8, Code39, UPC-A, UPC-E, Codabar, China post 25, Interleaved 2 of 5, ISBN/ISSN, Code 93, UCC/EAN-128, GS1 Databar, etc. 2D:PDF417 / QR code / Data Matrix / Aztec / Maxicode DPM .
Operation System
Support iOS / Android and Windows OS
Communication
3-in-1 connection USB+2.4GHz+ Bluetooth:
-USB Connection -2.4G wireless: 50M -Bluetooth module 7.0 Communication Mode: HID ,BLE. ( NO SPP ) Distance:10 meters (visual)
Power
Battery: 3.7V 1800mA Li-ion Current Consumption: 20mA Operating Current :220mA
Memory
16Mb (Ability to store more than 5000 codes)
Durability
Temperature in operation: -20 to 50 oC Temperature in storage: -40 to 70 oC Humidity in operation: 5 - 95% (non-condensing) Humidity in storage: 5 - 95% (non-condensing)
Physical
Dimensions (w x h x d): Scanner:165mm x 65mm x 94mm Weight: 178g (include battery)
