MJ-4209 Laser Barcode Scanner

Product description Product parameters Manual Download Driver Download Video

Product Model：MJ7580

Data type：1D & 2D bar codes

Reading Mode：image , handsfree

Interface：USB / RS232

Wireless：None

Product Model：MJ7580

Data type：1D & 2D bar codes

Reading Mode：image , handsfree

Interface：USB / RS232

Wireless：None

Performance	Image Sensor	752×480 CMOS
	Light Source	White LED
	Symbologies	2D PDF417, QR Code (QR1/2, Micro), Data Matrix (ECC200, ECC000, 050, 080, 100, 140)
		1D Code128, UCC/EAN-128, AIM-128, EAN-8, EAN-13, ISBN/ISSN, UPC-E, UPC-A, Interleaved 2 of 5, ITF-6, ITF-4, Matrix 2 of 5, Industrial 25, Standard 25, Code 39, Codabar, Code 93, Code 11, Plessey, MSI-Plessey, GS1-DataBar^TM(RSS), (RSS-14, RSS-Limited, RSS-Expand)
	Resolution	≥5mil
	Typical Depth of Field	EAN-13 10mm-55mm (13mil)
		PDF 417 15mm-35mm (6.67mil)
		Data Matrix 15mm-40mm (10mil)
		QR Code 10mm-50mm (15mil)
	Symbol Contrast	≥30% reflectance difference
	Scan Angle**	Roll: 360°, Pitch: ±40°, Skew: ±40°
	Field of View	Horizontal 80°, Vertical 56°
Mechanical/ Electrical	Interface	TTL-232, USB (HID-KBW, COM Port Emulation, HID-POS)
	Operating Voltage	3.0~5.5VDC
	Current@5VDC	Operating 160mA
		Sleep 12mA
	Dimensions	65.1(D)×61.1(W)×43.6(H)mm
	Weight	41.5g
Environmental	Operating Temperature	-20℃~+60℃ (-4°F~140°F)
	Storage Temperature	-40℃~+80℃（-40°F~176°F）
	Humidity	5%~95% (non-condensing)
	Ambient Light	0~100000lux (natural light)
Accessories	USB Cable	Used to connect the NLS-EM20 to a host device.

Product documentation：
